VS Code and Copilot on a Pi Zero 2 WH via SSHFS

Tutorial · Raspberry Pi · VS Code · SSHFS · ~20 min setup

This week on Talkshow Onpoint, we will be giving away some Raspberry Pi’s and this will be the last show of this season, so enter to Win Mo’ Pi!

The Pi Zero 2 can’t run VS Code — so we mount its filesystem over SSH and let your Mac or Windows machine do all the heavy lifting.

Raspberry Pi OS Lite (64-bit)· macOS & Windows· ~20 min setup

The Raspberry Pi Zero 2 WH packs a quad-core Cortex-A53 and built-in Wi-Fi into a board the size of a stick of gum. But its 512 MB of RAM means running VS Code locally is out of the question — the editor alone would consume most of it before you wrote a single line of code.

The solution is SSHFS (SSH Filesystem). Rather than running anything extra on the Pi, we mount its filesystem over the network onto your Mac or Windows machine. VS Code opens that mount like any local folder — and GitHub Copilot has no idea it’s talking to a tiny ARM board on your desk.

💻 Your machine (VS Code + Copilot) ⟷ 🔒 SSHFS tunnel ⟷ 🍓 Pi Zero 2 WH (only sshd)

The Pi only runs sshd — the standard SSH daemon. Nothing is installed on it beyond the OS. Your editor, Copilot, and all extension processes stay on your fast local machine.

Table of Contents

1. What you need

2. Flash Raspberry Pi OS Lite (64-bit)

3. SSH key setup

4. Mount with SSHFS on macOS

5. Mount with SSHFS on Windows

6. Open the mount in VS Code

7. GitHub Copilot

8. Tips & troubleshooting

What you need

• Raspberry Pi Zero 2 WH + micro-SD card (16 GB+)

• Micro-USB power supply (5V / 1.2A+)

• Your Wi-Fi SSID & password (2.4 GHz — the Pi Zero is single-band)

• macOS or Windows 10/11 on your dev machine

• Raspberry Pi Imager

• VS Code

• A GitHub account with Copilot access

Flash Raspberry Pi OS Lite (64-bit)

Open Raspberry Pi Imager. The built-in configuration wizard handles everything headless — no manual SD card editing needed.

Choose device, OS & storage

1. Choose Device → Raspberry Pi Zero 2 W

2. Choose OS → Raspberry Pi OS (other) → Raspberry Pi OS Lite (64-bit)

3. Choose Storage → select your SD card

Configure headless options (⚙️ gear icon)

Click the gear / “Edit Settings” button before writing:

• Hostname → e.g. pizero

• Enable SSH → turn on, select Allow public-key authentication only (we’ll add the key next)

• Username & password → set something other than the default

• Wi-Fi → SSID, password, and your country code

• Locale → your timezone

⚠️ The Pi Zero 2 WH only supports 2.4 GHz Wi-Fi. If you have separate 2.4 and 5 GHz SSIDs, make sure you enter the 2.4 GHz one. A 5 GHz network will silently fail.

Click Write and wait for it to finish (~2–3 minutes).

SSH key setup

SSHFS authenticates over SSH, so key-based auth is essential — you don’t want a password prompt interrupting your mount every time. Generate a key on your machine and copy it to the Pi on first boot.

Generate a key (if you don’t have one)

macOSWindows

ssh-keygen -t ed25519 -C "pi-zero"bash

Boot the Pi and copy your key

Insert the SD card, connect power, and wait 60–90 seconds for first boot. Then copy your public key over. You’ll need to use password auth just this once.

macOSWindows

ssh-copy-id youruser@pizero.localbash

Create an SSH config alias

This saves you typing the full address every time, and SSHFS will use it too. Add the following to ~/.ssh/config on your machine (create it if it doesn’t exist):

Host pizero
    HostName pizero.local
    User youruser
    IdentityFile ~/.ssh/id_ed25519
    ServerAliveInterval 60
    ServerAliveCountMax 3ssh config

Test that it works before moving on:

ssh pizerobash

You should land at the Pi shell with no password prompt. Type exit to return.

Mount with SSHFS on macOS

macOS needs two things: macFUSE (a kernel extension that lets FUSE filesystems work) and sshfs itself. The easiest way to get both is via Homebrew.

Install macFUSE

macFUSE requires a kernel extension, so it can’t be installed silently via Homebrew alone. Download and run the installer from the official site:

osxfuse.github.io → download the .dmg and run it. You’ll need to approve the system extension in System Settings → Privacy & Security and reboot.

Install sshfs via Homebrew

brew install gromgit/fuse/sshfs-macbash

ℹ️ The standard brew install sshfs formula was removed from Homebrew core when macFUSE went closed-source. The gromgit/fuse/sshfs-mac tap is the maintained replacement.

Create a mount point and mount the Pi

# Create a local folder to mount into
mkdir -p ~/mnt/pizero

# Mount
sshfs pizero:/home/youruser ~/mnt/pizero -o follow_symlinksbash

The Pi’s home directory is now accessible at ~/mnt/pizero. You can browse it in Finder too — it appears as a network drive.

Unmount when done

umount ~/mnt/pizerobash

Optional: mount on login with a shell alias

Add this to your ~/.zshrc or ~/.bashrc for a quick shortcut:

alias mountpi='sshfs pizero:/home/youruser ~/mnt/pizero -o follow_symlinks'
alias umountpi='umount ~/mnt/pizero'bash

Mount with SSHFS on Windows

Windows needs WinFsp (the Windows equivalent of FUSE) and SSHFS-Win. Both are free and install in minutes.

Install WinFsp

Download the installer from winfsp.dev and run it. Accept defaults.

Install SSHFS-Win

Download from github.com/winfsp/sshfs-win (Releases → latest .msi) and run the installer.

Map the Pi as a network drive

1. Open File Explorer

2. Right-click This PC → Map network drive…

3. Choose a drive letter (e.g. Z:)

4. In the Folder field enter:

\\sshfs\youruser@pizero.local\home\youruserunc path

1. Check Reconnect at sign-in if you want it to persist across reboots

2. Click Finish — Windows will connect using your SSH key

⚠️ If pizero.local doesn’t resolve, install Bonjour (available standalone from Apple, or bundled with iTunes). Alternatively, use the Pi’s IP address directly in the UNC path.

Or mount from PowerShell

net use Z: \\sshfs\youruser@pizero.local\home\youruserpowershell

The Pi’s home folder now appears as drive Z: in File Explorer and every file dialog.

Open the mount in VS Code

This is the straightforward part — VS Code doesn’t know or care that it’s looking at a mounted SSHFS directory.

macOSWindows

# Open your project folder directly from the terminal
code ~/mnt/pizero/projects/my-projectbash

Or use File → Open Folder and navigate to the mount point. Everything works as normal — file tree, search, editing. When you save a file, it’s written directly to the Pi’s SD card over the SSH tunnel.

The integrated terminal connects to the Pi

VS Code’s terminal still runs on your local machine. To get a shell on the Pi, open a separate terminal and SSH in:

ssh pizerobash

Run your code there. You can have VS Code editing files on the left and a Pi shell on the right — a clean split between editing and execution.

💡

Keep a terminal tab open with ssh pizero alongside VS Code. Edit in VS Code, switch to the terminal to run. It quickly becomes second nature.

GitHub Copilot

Because VS Code is running entirely on your local machine, Copilot works exactly as it does for any other project — no configuration changes needed.

Install the extension

1. Open the Extensions panel (Ctrl+Shift+X / Cmd+Shift+X)

2. Search GitHub Copilot and install it (GitHub.copilot)

3. Sign in to GitHub when prompted

4. Optionally install GitHub Copilot Chat for the inline chat panel

Open a .py file in your Pi project and start typing — Copilot’s suggestions appear inline as usual.

💡 Add a comment at the top of your file to give Copilot hardware context:

# Raspberry Pi Zero 2 W — using RPi.GPIO, Python 3.11

This steers suggestions toward correct GPIO pin numbers, library calls, and Pi-specific patterns rather than generic Python.

Tips & troubleshooting

Pi-side: free up RAM

Since you’re running headless, the GPU doesn’t need any shared RAM. Add this to /boot/firmware/config.txt:

gpu_mem=16config.txt

Then reboot. This recovers ~48 MB for your programs.

Pi-side: install dev tools

sudo apt update && sudo apt upgrade -y
sudo apt install -y git python3-pip python3-venv build-essentialbash

If the mount freezes or disconnects

SSHFS mounts can stall if the Pi goes idle or loses Wi-Fi. The ServerAliveInterval 60 in your SSH config helps, but if it does hang:

macOSWindows

# Force unmount a stale SSHFS mount
diskutil unmount force ~/mnt/pizerobash

If pizero.local doesn’t resolve

Find the Pi’s IP in your router’s admin panel (look for a device named pizero), then use the IP everywhere instead of the hostname. Update your SSH config’s HostName line to the IP address, and consider setting a DHCP reservation in your router so it never changes.

SD card write speed

File saves travel over Wi-Fi to the SD card, so you may notice a slight lag on large saves. Use a quality A2-rated card (e.g. SanDisk Extreme Pro) for noticeably better random write performance.

🔥 Avoid adding swap on the Pi if you can — swap on an SD card causes heavy write cycles and will shorten its life. Keep your Pi-side processes light and let your local machine handle the heavy lifting.

---

What to build next

With VS Code, Copilot, and a clean SSH connection to the Pi, you’re set up for real work:

🔌 GPIO & sensors

Write and edit your RPi.GPIO code in VS Code with Copilot, run it via the SSH terminal.

🌐 Flask web server

Build a lightweight API on the Pi, access it from your browser on the same network.

📡 MQTT & automation

Connect to Mosquitto and build sensor pipelines or Home Assistant integrations.

🐍 Virtual environments

Use python3 -m venv on the Pi — the venv folder shows up in your mount like any other directory.
